Introduction

Ten years ago, in mid-September, Hurricane Ivan stormed across the Caribbean and eastern U.S. regions. Ivan was a unique storm, having intensified to a Category 5 hurricane on the Saffir-Simpson Hurricane Scale three times, made landfall in the U.S. on two separate occasions, and caused an outbreak of more than 100 tornadoes in 9 states across the eastern U.S.

Ivan first made landfall on September 16 just west of Gulf Shores, Alabama, as a Category 3 hurricane. The system then travelled north through the eastern U.S., weakening to a tropical depression, but continuing to cause heavy rains and tornadoes. On September 18, Ivan converged with a frontal system over the Delaware-Maryland-Virginia peninsula, first strengthening, then again weakening as it turned south, and looping back around the Atlantic Ocean. The storm system crossed the southern peninsula of Florida early on September 21 and re-entered the Gulf of America where it regained strength. By September 24, the storm made landfall a second time, near Holly Beach, Louisiana, but this time as a tropical depression.

Hurricane Ivan resulted in nearly $15 billion in damage to the U.S. and more than $3 billion in the Caribbean Sea region. It was estimated that 95% of the homes and buildings in the Cayman Islands were damaged or destroyed. An area that suffered a lot of damage in the U.S. were the barrier islands that make up the Gulf Islands National Seashore (GUIS), including Santa Rosa Island, near Pensacola, Florida. About 60 meters (about 197 feet) of shoreline from the Fort Pickens area, located at the western end of Santa Rosa Island, eroded away and the coastal highway system suffered from severe washouts.

Image Caption

This image of Hurricane Ivan rotating over the Gulf of America on September 15, 2004, was captured by the Moderate Resolution Imaging Spectroradiometer (MODIS) instrument aboard the Aqua platform.

Major Findings

The white arrow in the Terra Advanced Spaceborne Thermal Emission and Reflection Radiometer (ASTER) image from September 21, 2004, points to a breach in the section of Fort Pickens Road along Santa Rosa Island, which occurred when Ivan hit the island. Surrounding sections of the road were damaged or washed over. The road also suffered damage during the 2005 hurricane season and did not fully reopen until May 2009. Use the comparison tool to view the changes in the Fort Pickens shoreline between 2004, post-Ivan, and 2014, ten years later.

Image Caption

Before Image:  ASTER image acquired Sep 21, 2004. Granule ID:  ASAST_L1B_00309212004164237_20101127103743_21699

Image Caption

ASTER image acquired May 5, 2014 after the storm event. Granule ID:  AST_L1B_00305052014163729_20140506114528_20422

References

Stewart, S.R., 2005, Tropical Cyclone Report: Hurricane Ivan 2 – 24 September 2004. National Weather Service National Hurricane Center, accessed August 27, 2014 .

Hapke, C.J., and Christiano, M., 2007, Long-term and Storm-related Shoreline Change Trends in the Florida Gulf Islands National Seashore: U.S. Geological Survey Open-file Report 2007-1392, p. 18.

Florida Department of Environmental Protection, 2014, Outstanding Florida Waters – March 2014, accessed September 2, 2014.

Note: Place names in this article were updated in February 2025 to reflect Executive Order No. 14172 and Secretary Order 3423.
